The ISO VAC 20 HY tank has been designed as a standard 20ft ISO container for the safe storage and transport of liquid hydrogen. A frame arrangement with Blair corner castings and lockable valve protection cabinets, containing the valves, gauges, instrumentation and all other connections.
The ISO VAC 20 HY tank is certified as a UN T75 Portable Tank with EN approvals, 10 bar working pressure and holding time of 24 days. This tank has approvals for road and sea transport.
The ISO VAC 20 HY also features high vacuum super-insulation, stacking capability 11 units high to ISO 1496-3 (213,360 kg max), full set of decals (including logos where supplied by customer), integral pressure building system, document holder and appropriate vacuum insulated pipe work to offer maximum performance & versatility to end user and operator.
